20,000 GALLON CLEMMER STEEL CRAFT VERTICAL STAINLESS STEEL PRESSURE MIX TANK
Sold
![Used 20,000 GALLON CLEMMER STEEL CRAFT VERTICAL STAINLESS STEEL PRESSURE MIX TANK](https://i.machineryhost.com/cffdb625cf9f77a09ca225f0cfd6fc59/large-used-20-000-gallon-clemmer-steel-craft-vertical-stainless-steel-pressure-mix-tank.jpg)
Description
1 - Used Clemmer Steel Craft approximately 20,000 gallon vertical stainless steel pressure mix tank. 12'-6"diameter X 24' high straight side. Welded dished heads. Internal rated Atmos/FV @ 400 F. Has (16) equally spaced internal heating baffles rated 100 PSIG @ -20 to 400 F. Heating baffles are fed by 6" inlets and outlets. Equipped with 100 HP top entering (4- Flight) stainless steel agitator, with bottom PTFE steady bearing. Top fittings: (2) 2”, (1) 12”, (1) 3”, (1) 18” manway. Bottom fittings: 20” to 8” center bottom outlet. (3) 1”, (1) 6”, (1) 2”, (2) 4”, (1) 3”, (1) 1/2”. Mounted on legs. Insulated. NB#: 631, S/N: 51170926. Weight Tank ONLY 27,700# Built 2007. FOB - LOCATION
Specifications
Manufacturer | Clemmer Steel Craft |
Condition | Used |
Stock Number | 10174 |
Size | 20000 gallons |
