NEW 300 GALLON TRIPLE MOTION MIX TANK WITH HIGH SHEAR DISPERSER - S/S - JACKETED
or
Call 216-409-1394
Description
NEW 300 Gallon Triple Motion High Shear Mix Tank - 316L S/S - 75 PSI Jacket
- Interior Contact Surfaces: 316L Stainless Steel with #4 Finish
- Exterior Non-Contact Surfaces: 304 Stainless Steel with #4 Finish
- Heat Transfer Surface: Side & Bottom Stainless Steel Dimple Jacket Rated 75 PSI (ASME/NB Code Stamped)
- Insulation: 2" Thick Rockwool
- Top Mount Triple Motion Agitation Consisting of
- 20 HP High Shear Disperser (1750 RPM)
- 7.5 HP Side & Bottom Anchor Sweep Blade (29 RPM)
- 3 HP Offset Paddle Agitator (54 RPM)
- UL Listed Motors
- Tank top: Inverted cone with 15 degree slope head with double open hinged lids, CIP cleaning, 2 spray balls.
- Tank bottom Conical with 15 or 30 degree slope and center outlet, flat bottom structure optional.
- Inlet/outlet ports Sanitary clamp connections.
- Temperature indicating 1/2" FNPT and 1 1/4" UNEF temperature sensor interface.
- Legs Adjustable stainless steel legs.
- In stock
Packing size 110" x 67" x 75"
2,866lbs
Specifications
| Manufacturer | Hongda |
| Model | Mixing Tank |
| Year | 2025 |
| Condition | New |
| Stock Number | 11124 |
| Size (smallest to largest) | 300.00 |
